ALV510 series solenoid valve adopts fixed O- ring hermetic sealing technology. With self-cleaning function, it can discharge the impurities, oil stain and dust etc. in air supply out of the body. The surface of valve body is free of any breathing holes. It can effectively prevent the external liquid, dust, impurity and other foreign matters from entering the inside of valve body and has greatly extended the service life of the product to the utmost extent. |
|
|
 |
|
|
Dimensions of ALV510F3：
Main Features:
1.The same spool valve can be adapted for 3/2 NC or 5/2 functions for controlling double-acting and single-acting pneumatic actuators. Manual override on the pilot body.
2. All the exhaust ports of this spool valve are connectable which offer excellent environmental protection against the ingress of liquids, dusts or other foreigh matter.
3.The same spool valve can be fitted with IP65 NEMA4, 4X coil(C0) or with Ex mb II T4 or T5 coil(C7) |
|
|
|
Dimensions of ALV51P1/P2：
Main Features:
1.All the exhaust ports of this spool valve are connectable which offer excellent environmental protection against the ingress of liquids, dusts or other foreigh matter.
2.The same spool valve can be fitted with IP65 NEMA4, 4X coil(C0) or with Ex mb II T4 or T5 coil(C7). |
|
|
|
